PRESSOSTATIC PUMP JABSCO PARMAX HD5 12V 19LPM

Description

Pressurizing bulkhead pumps supply the water supply circuit of the vessel with the required flow that can lie from a simple drop to the full flow. The pump is controlled by a switch that perceives the pressure drop as soon as a battery is opened and activates the pump. It closes as soon as the pressure rises above a predetermined limit once the battery is shut down. They work with all types of batteries from 10-13 mm. To choose the appropriate pump simply check the size of the system you want to be served and the number of outputs you want to operate at the same time. Pressurizing pumps are self-draining, operate quietly and can stay dry for a long time. We recommend that before each period of deactivation of the system you turn off the pump and then turn on the battery switch to decompress the system. This lengthens the life of the pump.

Description

New series designed specifically for boats that require smooth low flow at a reasonable price. They have three chambers and are addressed to boats that have showers, water heater and up to three batteries.

Smooth flow

Low noise level

Resistance against corrosion

Shelling material: Polypropylene

Aperture: Santoprene

Valves: EPDM

Thermal motor protection

Features

Provision: 7 lt/min

Aspiration: 2,4 m

Connection: 1/2 in (13 mm)

Voltage: 12 V

Consumption: 3,5 A

Security: 7 A

Maximum pressure: 25 psi (1,7 bar)

Weight: 1,4 kg
